| Model No. ?AUXT2500 |
|
|
||
| number of cavity? | 1 | 2 | 3 | 4 |
| clamping stroke? | 160 mm | 160 mm | 160 mm | 160 mm |
| production? | 800pcs/hr | 1500pcs/hr | 2100pcs/hr | 2600pcs/hr |
| total power? | 31 kw | 25kw | 40 kw | 55 kw |
| actual power consumption? | ≤10 kw | ≤14 kw | ≤18 kw | ≤23 kw |
| pressure for working? | 10 kg | 10 kg | 10 kg | 10 kg |
| pressure for blowing? | 30 kg | 30 kg | 30 kg | 30 kg |
| flow rate for working? | 1.0 m3 | 2.5 m3 | 1.5 m3 | 1.5 m3 |
| flow rate for blowing? | 1.2 m3 | 3.5 m3 | 3.5 m3 | 3.5 m3 |
| neck diameter? | 24-40 mm | 40-120 mm | 40-100 mm | 40-80 mm |
| max diameter? | 150 mm | 140 mm | 140 mm | 115 mm |
| max height? | 320 mm | 320 mm | 320 mm | 320 mm |
| machine size LxWxH? | 2.2x1.75x2.1 m | 2.6x2.2x2.2 m | 3.5x2.2x2.2 m | 3.5x2.2x2.2 m |
| auto loader LxWxH? | 1.7x1.7x2.7 | 1.7x2.7x2.7 | 1.7x2.7x2.7 | 1.7x2.7x2.7 |
| machine weight? | 1450 kg | 1800 kg | 2500 kg | 3000 kg |
