ASNTO AUXT1500 bottle blowing machine |SNTO|AUXT1000 bottle blowing machine,pet bottle blowing
| Model No.? AUXT1500 | 1 | 4 | 6 |
| number of cavity? | 1 | 4 | 6 |
| clamping stroke? | 120 mm | 120 mm | 120 mm |
| production? | 900pcs/hr | 3200pcs/hr | 4800pcs/hr |
| total power? | 31 kw | 45 kw | 65 kw |
| actual power consumption? | ≤10 kw | ≤18 kw | ≤25 kw |
| pressure for working? | 10 kg | 10 kg | 10 kg |
| pressure for blowing? | 30 kg | 30 kg | 30 kg |
| flow rate for working? | 0.8 m3 | 2.5 m3 | 3.0 m3 |
| flow rate for blowing? | 1.0 m3 | 3.0 m3 | 4.0 m3 |
| neck diameter? | 24-38 mm | 24-32 mm | 24-32 mm |
| max diameter? | 110 mm | 95mm | 95 mm |
| max height? | 320 mm | 320 mm | 320 mm |
| machine size LxWxH? | 2.1x1.65x2.1 m | 2.5x2.2x2.2 m | 4.5x2.2x2.2 m |
| auto loader LxWxH? | 1.7x1.7x2.7 m | 1.7x2.7x2.7 | 1.7x2.7x2.7 |
| machine weight? | 1250 kg | 2800 kg | 3800 kg |
Zhejiang Huangyan Plastic Machinery Co. Ltd.
Tel: +86-576-84325111
E-mail: snto@snto.com.cn
Address: http://www.zol-jz.com
Address: Taizhou City, Zhejiang province Huangyan District in Jiangkou Road No. 88
