ASNTO XT bottle blowing machine |SNTO| bottle blowing machine,pet bottle blowing
| Model No. ?XT600 | 1 | 3 | |
| number of cavity? | 1 | 3 | |
| clamping stroke? | 100 mm | 100 mm | |
| production? | 1500pcs/hr | 3400pcs/hr | |
| total power? | 22 kw | 28 kw | |
| actual power consumption? | ≤8 kw | ≤12 kw | |
| pressure for working? | 10 kg | 10 kg | |
| pressure for blowing? | 30 kg | 30 kg | |
| flow rate for working? | 0.6 m3 | 1.5 m3 | |
| flow rate for blowing? | 0.8 m3 | 3.5 m3 | |
| neck diameter? | 12-99 mm | 24-40 mm | |
| max diameter? | 90 mm | 70 mm | |
| max height? | 240 mm | 240 mm | |
| machine size LxWxH | 2x1.5x1.9 m | 3.5x1.8x2 m | |
| machine weight? | 980 kg | 1600 kg | |
| Model No. ?XT1500 | 1 | 2 | 3 |
| number of cavity? | 1 | 2 | 3 |
| clamping stroke? | 100 mm | 100 mm | 100 mm |
| production? | 1300pcs/hr | 2200pcs/hr | 3300pcs/hr |
| total power? | 22 kw | 35 kw | 25 kw |
| actual power consumption? | ≤8 kw | ≤13 kw | ≤10 kw |
| pressure for working? | 10 kg | 10 kg | 10 kg |
| pressure for blowing? | 30 kg | 30 kg | 30 kg |
| flow rate for working? | 0.6 m3 | 2.5 m3 | 0.6 m3 |
| flow rate for blowing? | 1.0 m3 | 3.5 m3 | 1.0 m3 |
| neck diameter? | 12-99 mm | 24-38 mm | 12-99 mm |
| max diameter? | 90 mm | 90 mm | 90 mm |
| max height? | 280 mm | 280 mm | 280 mm |
| machine size LxWxH? | 2x1.5x2.0 m | 2.2x2.0x2 m | 2.2x2.2x2.0m |
| machine weight? | 1100 kg | 1600 kg | 2200 kg |
| Model No. ?XT2500 | 1 | 2 | |
| number of cavity? | 1 | 2 | |
| clamping stroke? | 120 mm | 120 mm | |
| production? | 1200pcs/hr | 2100pcs/hr | |
| total power? | 25 kw | 45kw | |
| actual power consumption? | ≤10 kw | ≤18 kw | |
| pressure for working? | 10 kg | 10 kg | |
| pressure for blowing? | 30 kg | 30 kg | |
| flow rate for working | 0.8 m3 | 2.5 m3 | |
| flow rate for blowing | 1.2 m3 | 3.5 m3 | |
| neck diameter? | 12-105 mm | 24-38 mm | |
| max diameter? | 110 mm | 110 mm | |
| max height? | 320 mm | 320 mm | |
| machine size LxWxH? | 2x1.65x2.1 m | 3.5x1.8x2 m | |
| machine weight? | 1250 kg | 1600 kg |
