鑫泰吹瓶機|ASNTO|AUXT600吹瓶機系列
特點|TECHNICAL FEATURES
??密集型加熱節能型設計 ? ?Intensive Heating Systemr Power Saving?Ecnomical Machine
??占地面積小 ??Space Saving?Smart Machine?
??可選擇排氣回收功能? ? ?Optional Air Recyle Use Function
??可直接連接罐裝機 ? ??Capable Of Connecting Filling Machine
??每腔瓶坯加熱及吹瓶延時調整都可獨立控制 ? ? ?Preform Heating And Blowing Delay Individu-ally Controlled
| Model No.型號? AUXT600 | 1 | 3 | 4 | 6 | 8 | 10 |
| number of cavity 模穴數 | 1 | 3 | 4 | 6 | 8 | 10 |
| clamping stroke 開模行程 | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| production 理論產量 | 1500pcs/hr | 3300pcs/hr | 4000pcs/hr | 5500pcs/hr | 7500pcs/hr | 14000pcs/hr |
| total power 總裝機容量 | 22 kw | 30kw | 38 kw | 55 kw | 70 kw | 90 kw |
| actual power consumption 實際耗電量 | ≤8 kw | ≤12 kw | ≤12 kw | ≤18 kw | ≤25 kw | ≤38 kw |
| pressure for working 動作用氣壓力 | 10 kg | 10 kg | 10 kg | 10 kg | 10 kg | 10 kg |
| pressure for blowing 允許吹氣壓力 | 30 kg | 30 kg | 30 kg | 30 kg | 30 kg | 30 kg |
| flow rate for working 動作用氣量 | 0.8 m3 | 1.5 m3 | 1.5 m3 | 3.0 m3 | 4.0 m3 | 2.0 m3 |
| flow rate for blowing 吹氣用氣量 | 0.8 m3 | 2.0 m3 | 2.0 m3 | 3.5 m3 | 4.5 m3 | 5.0 m3 |
| neck diameter 允許瓶口直徑 | 22-38 mm | 24-32 mm | 24-32 mm | 24-32 mm | 24-32 mm | 24-32 mm |
| max diameter 允許瓶身直徑 | 68 mm | 68 mm | 68 mm | 65 mm | 65 mm | 65 mm |
| max height 允許瓶身高度 | 240 mm | 240 mm | 240 mm | 240 mm | 230 mm | 230 mm |
| machine size LxWxH 機器尺寸 | 2.2x1.7x1.7 m | 3.5x1.8x2 | 2.3x2.1x2.1 m | 2.6x2.2x2.2 m | 3.8x2.2x2.2 m | 5.1x2.2x2.2 m |
| auto loader LxWxH 上料機構 | 1.7x1.7x2.7 m | 1.7x2.7x2.7 m | 1.7x2.7x2.7 m | 1.7x2.7x2.7 | 1.7x2.7x2.7 | 1.7x2.7x2.7 |
| machine weight 機器重量 | 1800 kg | 2000kg | 2200 kg | 2800 kg | 3500 kg | 6000 kg |
